Take a look at these amazing shots of a Chinook helicopter delivering a massive new radar to the top of the Rock.
On Mar. 2, 2022, a RAF Chinook helicopter carried out a pretty peculiar mission when it delivered a new radar to the top of the Gibraltar rock. The ATC radar of RAF Gibraltar airfield, that serves also as the commercial airport of the British Overseas Territory, is located at the top of the iconic rock. The radar needed to be replaced, a task that could not be completed by road, as the roads to the top of the rock are too narrow for ground transportation.
For this reason, a RAF Chinook helicopter (ZA680) was flown from the UK via Portugal and undertook the lift of the massive radar, a 11.8 meter structure weighting over 8,000 kg, to the summit, site of the former Rock Gun Battery.
The Aviationist‘s contributor David Parody took the stunning photos of the Chinook helicopter at work during the radar lift operation at the summit of the Rock.
According to Aquila Air Traffic Management Services that delivered the new radar to serve RAF Gibraltar, the new radar was transported as an underslung load by the Chinook in four parts. The radar’s rotational turning gear, two large antennae and the “horn” – the transmit and receive section of the antenna – were each lifted in four separate journeys. Also flown to the top of the Rock was a new navigational beacon.
A temporary helicopter landing platform was built at Rock Gun Battery especially for the operation. The platform allowed the helicopter to land the loads above the rough and protected ground of the nature reserve, that is known for the apes that populate the Rock and are a major tourist attraction.
More from The Aviationist
The Incredible Armada of Aircraft Behind 1969’s Battle of Britain Film
On Sept. 15, 1969, cinema audiences were treated to a dramatic portrayal…
US Approves Possible Sale of Nine KC-46A Pegasus Tankers for Japan
The latest deal would take the number of KC-46As in Japan’s inventory…
U.S. State Department Approves $7.2B Sale Of F-35 Jets To Romania
The Foreign Military Sale’s approval comes after Romania announced the plan to…
Wooden Avengers, Target Kites, and Draftees: How America’s First New Deal Community Took the Fight to the Axis
Situated in the quiet hills of West Virginia, the small town of…
DARPA Awards BAE Systems $4 Million for Autonomous Beyond Visual Range Air Combat Program
Autonomy solutions for BVR combat will initially be developed and demonstrated on…
The lift was originally scheduled for Nov. 21, 2021, but the operation had to be postponed due to bad weather and rescheduled.
The upgrade to RAF Gibraltar’s Air Traffic Management system is part of an MOD wide 1.5 billion GBP investment in to air traffic management systems, known as Programme Marshall. The programme includes a 400 million GBP investment in advanced surveillance radars and a wide range of sophisticated equipment such as tower systems, new surveillance and navigation aids and radios, with the purpose to ensure increased reliability for air traffic management, improved safety and estimated savings of 317 million GBP for the MOD over the course of the 22-year partnership with Aquila to support the new equipment.
